EC040420.E
200 × 400 × 400 mm
Material: Mild steel, Steel
Category: All Products, Diecast & Metal, Electrical, Heavy Duty
Enclosure Customisation
CNC Holes, Slots, Shapes, Routing, Custom Colours, Printing and Assembly Kits are available for this product.
Manufacturing
PCB Assembly, Wiring, Keypads & Components right up to a full Turnkey Box-Build.
Product Details
EC040420.E
ETA E COR EMC wall-mount enclosure with cable entry plate(s), Single window door, Concealed hinge, 1/4-turn double-bit latch, NEMA/UL Type 1,3R,4,12,13; IP66, Steel, RAL 7035 Light Grey, 16 x 16 x 8 nominal (400 x 400 x 200mm – HxWxD)”
Configuration: Single blank door
Dims: 200x400x400mm
Environmental Ratings: NEMA/UL TYPE 1
Latch Type: Quarter-turn, double-bit key
Number of latches: 1
Finish: Textured thermosetting powder
Colour: Grey
Material: Enclosure and door: sendzimir sheet steel with conductive and shielding gasket
Thickness:
Paint: Ciclo standard elettrostatico E DUP ETA: verniciatura liquida con processo di elettroforesi catodica con resina epossidica e finitura con polveri epossipoliestere termoindurenti.
Impact Rating: IK10
Contents: Solution supplied with enclosure, reversible door with diam. 3,0mm double bit locking systen; nr. Welded profiles, mounting plate and set of screws for grounding and assembly.
Technical
| Dimensions | 200 × 400 × 400 mm |
|---|---|
| Colour | Grey |
| Height | 400 |
| Width | 400 |
| Material | Mild steel, Steel |
| Shape | Rectangular/Square |
| Length | 200 |
| Mounting | Wall Mount |
| Feature | |
| Manufacturer | ETA |
